FPDL3TC4 | FPD-Link™ III Multimedia Stream Programmable Generator
- DS90UB933 serializer over coax
- Fully supported chipset functions
- Pixel-perfect reference pattern generator
- Programmable frame size, synchs & porches
- Customizable video frame content from image files
- Still frame and circular buffer movie modes
- Real-time adjustable overlays
- Optional arbitrary audio generator
- Bidirectional sideband communication support
- Programmable I/O trigger
- Description
- Additional information
- DOCUMENTATIONS
- USE CASE
Description
The Flexmedia XM FPDL3TC4 module is a versatile video generator.
It can then be used to generate and transmit multimedia digital streams to multimedia digital stream receivers compatible with DS90UB933.
The FPDL3TC4 module is ideally suited for test applications in the automotive industry:
- Multi-camera driver assistance systems
- Advanced Driver Assistance Systems (ADAS): Camera, LiDAR and RADAR
Additional information
| Weight | 0,180 kg |
|---|---|
| Dimensions | 24 × 43 × 141 cm |
The multimedia data link configuration implies having detailed SerDes information/datasheets (subject to NDA) as well as application specific video formats, encodings, etc. and subsystem implementation.
As the multimedia SerDes chipset may hold complex/undisclosed features, direct access to the chipset vendor support may be required in some cases.
Flexmedia XM Video Generators and Analyzers – Getting Started
1 file(s) 462.98 KB
